NSE6_FAZ-7-2 Practice Questions

To send reports from FortiAnalyzer to an external server, you must configure the output profile. This

involves specifying the method (FTP, SFTP, or SCP), server IP, username, password, and the directory

where the report will be saved. Additionally, you have the option to delete the report after it has

been uploaded to the server.

Reference: FortiAnalyzer 7.2 Administrator Guide, "Enable uploading of generated reports to a

server" section.

When only some of the expected logs from a FortiGate device are being received on FortiAnalyzer, it

often indicates a configuration issue on the FortiGate side. Proper logging configuration on FortiGate

involves specifying what types of logs to generate (e.g., traffic, event, security logs) and ensuring that

these logs are directed to the FortiAnalyzer unit for storage and analysis. If the logging settings on

FortiGate are not correctly configured, it could result in incomplete log data being sent to

FortiAnalyzer. This might include missing logs for certain types of traffic or events that are not

enabled for logging on the FortiGate device. Ensuring comprehensive logging is enabled and

correctly directed to FortiAnalyzer is crucial for full visibility into network activities and for the

effective analysis and reporting of security incidents and network performance.

FortiAnalyzer allows for the inclusion of existing reports in the backup files, providing a

comprehensive backup of configurations and data. Additionally, the backup files can be configured to

be uploaded to SCP and SFTP servers, ensuring secure transfer and offsite storage of backup data.

This can be configured both in the GUI and the CLI, providing flexibility in how backups are scheduled

and managed.

Reference: FortiAnalyzer 7.4.1 Administration Guide, "Scheduling automatic backups" section.

The purpose of executing the provided CLI commands, which include setting the log-checksum to

md5-auth, is to ensure the integrity of the log files. This setting is used to record the MD5 hash value

of log files, which is a widely used cryptographic hash function that produces a 128-bit (16-byte) hash

value. By using MD5 authentication, FortiAnalyzer ensures that the log files have not been altered or

tampered with during transit, thereby verifying their integrity upon receipt. This is not related to

encrypting log transfers, scheduling reports, or creating secure channels for OFTP (Over-the-

FortiGate Protocol) processes.

For FortiAnalyzer reports, an output profile must be configured before reports can be generated and

sent to an external server or system. This output profile determines how the reports are distributed,

whether by email, uploaded to a server, or any other supported method. The options such as auto-

cache, saving reports in CSV format, or reports availability across different ADOMs are separate

features/settings and not directly related to the requirement of having an output profile for report

generation.

Based on the provided exhibit, which shows partial outputs of the system status and global settings

for FortiAnalyzer devices, the devices cannot be configured as peers in an HA (High Availability)

cluster. This is indicated by the HA Mode status being set to 'Stand Alone' for the displayed

FortiAnalyzer device. For devices to be part of an HA cluster, they would need to have compatible HA

configurations, and usually, they should not be in 'Stand Alone' mode. Additionally, the exhibit only

shows information for one FortiAnalyzer, so it cannot be determined if there is another device ready

to form an HA cluster with it.

On FortiAnalyzer, analytics logs refer to the logs that have been processed, indexed, and then stored

in the SQL database. This process allows for efficient data retrieval and analytics. Unlike basic log

storage, which might involve simple compression and storage in a file system, analytics logs in

FortiAnalyzer undergo an indexing process. This enables advanced features such as quick search,

report generation, and detailed analysis, making it easier for administrators to gain insights into

network activities and security incidents.

Reference: FortiAnalyzer 7.2 Administrator Guide - "Log Management" and "Data Analytics" sections.

Link aggregation is a method used to combine multiple network connections in parallel to increase

throughput and provide redundancy in case one of the links fail. This feature is used in network

appliances, including FortiAnalyzer, to add redundancy to the network connections, ensuring that

there is a backup path for traffic if the primary path becomes unavailable. Reference: The

FortiAnalyzer 7.4.1 Administration Guide explains the concept of link aggregation and its relevance to

The configuration displayed in the exhibit indicates that the FortiAnalyzer is set up with a cluster

virtual IP address of 192.168.101.222 assigned to interface port1. This setup is typically used for the

FortiAnalyzer to receive logs on that interface when operating in a High Availability (HA)

configuration. The exhibit does not provide enough information to conclude whether this

FortiAnalyzer will be the primary unit in the HA cluster or the duration for the failover trigger; it only

confirms the interface configuration for log reception. Reference: Based on the FortiAnalyzer 7.4.1

Administration Guide, the similar configurations for HA and log reception are discussed, which would

be relevant for understanding the settings in FortiAnalyzer 7.2.

The exhibit shows a packet capture with a syslog message containing a log event from a FortiGate

device. This log event includes several details such as the date, time, and event message. The

corresponding image that matches this packet capture would be the one which shows that the

FortiGate device has logs being received in real-time, as indicated by the highlighted section in the

packet capture where it mentions "real-time". Therefore, Option A is the correct answer because it

shows logs with "Real Time" status for the FortiGate-VM64 device, indicating that this FortiAnalyzer

is currently receiving real-time logs from the device, matching the activity in the packet capture.

Reference: Based on the provided exhibits and the real-time logging information, correlated with the

knowledge from the FortiAnalyzer 7.2 Administrator documentation regarding log reception and

device management.
